ENHANCED SEED-TRENCH CLOSING WITH RAPID STARTER UPTAKE
PAYBACK PLUS IN THE FIRST YEAR
Use these ROI calculators to see how quickly an investment in 360 WAVE pays you back. Just enter your costs, your acres, expected yield increase and corn price. Test different yield responses and different crop prices to see how it impacts ROI.
Click here for side-by-side yield trials that can help you determine the yield increase to enter into the calculator.
For product price, either use the full cost of the product, or the incremental upgrade cost - the difference between the standard replacement part cost and the 360 upgrade parts.
360 WAVE CLOSING SYSTEM PROFIT CALCULATOR
360 WAVE STARTER SYSTEM PROFIT CALCULATOR
Surrounding corn seeds with moist soil ensures uniform emergence. And uniform emergence leads to better yields. 360 WAVE gently surrounds seeds with moist soil by peeling a band of moist soil from the lower half of the seed trench and rolling it over the seed. That reduces the risk of slotting and air pockets in dry, wet and ideal seedbed conditions.
Improved trench closing is just one reason to add 360 WAVE to your planter. 360 WAVE is an angled blade that slices through the seed-trench sidewall and delivers starter to the side and below the seed. Years of field trials show that the best starter response comes from placing starter below the seed and 3/4" from the seed trench. This placement provides seed safety and quick access to the starter by the developing seed. Unfortunately, the attachments that have been available to execute this placement have been hard to install, maintain and keep aligned. So, 360 set out to develop a starter placement tool that captures all of the benefits of placing starter below the seed and 3/4" from the seed trench and eliminates the problems.
The 360 WAVE mounts to the rear of the planter row-unit shank. This simplifies installation and ensures alignment with the double-disk openers. The 360 WAVE blade swivels to follow the seed trench on curves but includes a stop to limit travel so the blade never places starter in the seed trench. The blade is spring loaded so that it can react to rocks and obstructions without becoming bent or misaligned.
The 360 WAVE has been in development for the last 16 months. It will be field tested over the next nine months on a limited number of planters over a wide range of soils and crop conditions. Pending successful testing through the spring of 2020, 360 WAVE will be in limited production for the 2021 North American planting season.
The 360 WAVE creates a "wave" of moist soil that rolls over the seed to simplify the job of the closing wheels.
The 360 WAVE blade pivots - self aligning in the trench. That means it follows the trench on curves. A stop prevents the blade from pivoting over the seed trench on tight left turns.
The spring-loaded 360 WAVE blade moves up and over obstacles to prevent damage, lower down force demands and maintain depth.
The liquid tube positions starter fertilizer 3/4" to the right of the seed trench and below the seed. The hardened knife edge increases wear life.
Creates a wave of moist soil that rolls over the seed to simplify the job of the closing wheels.
Follows the trench on curves.
Spring-loaded to move up and over obstacles to prevent damage, lower down force demands and maintain depth.
Positions starter fertilizer 3/4" to the right of the seed trench and below the seed.
